{"Contact Classification":"19Signal","Strain Relief":"No","Number of Terminals":"19","Family":"MS","Voltage Rating":"850VDC/600VAC","Gender":"PL","Body Orientation":"Straight","Rad Hardened":"No","Contact Gender":"SKT","Mounting Style":"Cable","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 175C","Product Diameter (mm)":"30.05(mm)","Termination Method":"Crimp","Shell Size / Insert Arrangement":"14-19","Number of Contacts":"19(POS)","Type":"Circular","Product Length (mm)":"36.07(mm)","Contact Mat...

{"Contact Classification":"19Signal","Strain Relief":"No","Number of Terminals":"19","Family":"MS3476","Voltage Rating":"850VDC/600VAC","Gender":"PL","Body Orientation":"Straight","Product Height (mm)":"Not Required(mm)","Rad Hardened":"No","Contact Gender":"SKT","Mounting Style":"Cable","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 175C","Product Depth (mm)":"Not Required(mm)","Product Diameter (mm)":"30.05(mm)","Termination Method":"Crimp","Shell Size / Insert Arrangement":"14-19","Number of...

{"Status":"ACTIVE","Body/Shell Style":"PLUG","MIL Conformance":"Yes","Total Number of Contacts":"19","Option":"GENERAL PURPOSE","Mounting Type":"CABLE","Contact Finish - Mating":"NOT SPECIFIED","Shell Finish":"CADMIUM PLATED","Backshell Type":"SOLID","Environmental Characteristics":"CORROSION RESISTANT; ENVIRONMENT RESISTANT; FLUID RESISTANT","Contact Finish - Termination":"NOT SPECIFIED","Contact Gender":"FEMALE","Coupling Type":"BAYONET","Manufacturer Series":"MS3476","Termination Type":"CRIMP","Shell Siz...

{"Category":"Connectors, Interconnects","Current Rating":"7.5A","Voltage - Rated":"600VAC","Operating Temperature":"-65\u00b0C ~ 200\u00b0C","Shell Size, MIL":"-","Contact Finish Thickness":"-","Number of Positions":"19","Datasheets":"MIL-C-26482, Series 2 Catalog","Standard Package":"1","Family":"Circular Connectors","Shell Size - Insert":"14-19","Connector Type":"Plug, Female Sockets","Contact Finish":"Gold","Fastening Type":"Bayonet Lock","Termination":"Crimp","Features":"-","Ingress Protection":"Environ...

{"Current Rating":"7.5 A","Shell Material":"Aluminum","MIL Type":"MIL-DTL-26482 II","Termination Style":"Crimp","Insert Arrangement":"14-19","Shell Size":"14","Number of Positions":"19 Position","Product Category":"Circular MIL Spec Connector","Brand":"Amphenol Aerospace","Tradename":"26482","Product Type":"Plugs","Shell Plating":"Olive Drab Cadmium","Manufacturer":"Amphenol","Voltage Rating":"600 V","Wire Gauge":"24-20","Mating Style":"Bayonet","Contact Gender":"Socket (Female)","Shell Style":"In-Line","Ro...

{"Status":"ACTIVE","Body/Shell Style":"PLUG","MIL Conformance":"Yes","Option":"GENERAL PURPOSE","Mounting Type":"CABLE","Contact Finish - Mating":"NOT SPECIFIED","Shell Finish":"CADMIUM PLATED","Backshell Type":"SOLID","Environmental Characteristics":"ENVIRONMENT RESISTANT","Contact Finish - Termination":"NOT SPECIFIED","Contact Gender":"FEMALE","Coupling Type":"BAYONET","Manufacturer Series":"MS3476","Mating Information":"MULTIPLE MATING PARTS AVAILABLE","Shell Size":"14","Shell Material":"ALUMINUM ALLOY",...

{"Contact Classification":"19Signal","Strain Relief":"No","Number of Terminals":"19","Family":"MS","Voltage Rating":"600VAC","Gender":"PL","Body Orientation":"Straight","Product Height (mm)":"Not Required(mm)","Rad Hardened":"No","Contact Gender":"SKT","Mounting Style":"Cable","Number of Ports":"1(Port)","Operating Temp Range":"-65C to 200C","Product Depth (mm)":"Not Required(mm)","Product Diameter (mm)":"30.04(mm)","Termination Method":"Crimp","Shell Size / Insert Arrangement":"14-19","Number of Contacts":...

{"Contact Classification":"19Signal","Type":"Circular","Current Rating (Max)":"7.5(A)","Product Height (mm)":"Not Required(mm)","Contact Plating":"Gold","Termination Method":"Crimp","Shell Size / Insert Arrangement":"14-19","Strain Relief":"No","Shell Plating":"Cadmium","Voltage Rating":"850VDC/600VAC","Gender":"PL","Body Orientation":"Straight","Contact Gender":"SKT","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 175C","Product Diameter (mm)":"30.04(mm)","Family":"MS","Number of Terminals":"19...
