{"Contact Classification":"29Signal","Strain Relief":"No","Number of Terminals":"29","Family":"MS27656","Voltage Rating":"850VDC/600VAC","Gender":"RCP","Body Orientation":"Straight","Product Height (mm)":"46.02(mm)","Rad Hardened":"No","Contact Gender":"PIN","Mounting Style":"Wall","Number of Ports":"1(Port)","Operating Temp Range":"-65C to 175C","Product Depth (mm)":"46.02(mm)","Termination Method":"Crimp","Shell Size / Insert Arrangement":"25-29","Number of Contacts":"29(POS)","Type":"Circular","Product L...

{"Strain Relief":"No","Family":"MS27656","Product Height (mm)":"46.02(mm)","Voltage Rating":"850VDC/600VAC","Number of Terminals":"19","Body Orientation":"Straight","Termination Method":"Crimp","Contact Gender":"PIN","Product Length (mm)":"33.6(mm)","Mounting Style":"Wall","Number of Ports":"1(Port)","Rad Hardened":"No","Product Depth (mm)":"46.02(mm)","Product Diameter (mm)":"Not Required(mm)","Gender":"RCP","Operating Temp Range":"-65C to 175C","Shell Size / Insert Arrangement":"25-29","Number of Contacts...

{"Category":"Connectors, Interconnects","Current Rating":"13A","Voltage - Rated":"600VAC, 850VDC","Operating Temperature":"-65\u00b0C ~ 175\u00b0C","Featured Product":"MIL-DTL-38999 Series I, II","Shell Size, MIL":"-","Contact Finish Thickness":"50\u00b5in (1.27\u00b5m)","Number of Positions":"29","Datasheets":"MIL-DTL-38999, JT, LJT Series Catalog","Standard Package":"1","Family":"Circular Connectors","Shell Size - Insert":"25-29","Connector Type":"Receptacle, Male Pins","Contact Finish":"Gold","Fastening ...

{"Status":"ACTIVE","Body/Shell Style":"RECEPTACLE","MIL Conformance":"Yes","Total Number of Contacts":"29","Option":"GENERAL PURPOSE","Mounting Type":"PANEL","Contact Finish - Mating":"NOT SPECIFIED","Backshell Type":"SOLID","Shell Finish":"CADMIUM PLATED","Contact Finish - Termination":"NOT SPECIFIED","Contact Gender":"MALE","Coupling Type":"BAYONET","Manufacturer Series":"MS27656T","Termination Type":"CRIMP","Shell Size":"25","Shell Material":"ALUMINUM ALLOY","Connection Type":"MIL SERIES CONNECTOR","Cont...

{"Status":"ACTIVE","Body/Shell Style":"RECEPTACLE","MIL Conformance":"Yes","Total Number of Contacts":"29","Option":"GENERAL PURPOSE","Mounting Type":"PANEL","Contact Finish - Mating":"GOLD OVER NICKEL","Shell Finish":"OLIVE GREEN CADMIUM","Backshell Type":"SOLID","Environmental Characteristics":"FLUID RESISTANT","Contact Finish - Termination":"GOLD OVER NICKEL","Contact Gender":"MALE","Coupling Type":"BAYONET","Manufacturer Series":"MS27656","Mating Information":"MULTIPLE MATING PARTS AVAILABLE","Shell Siz...
