{"Brand/Series":"CTX10 Series","Tolerance":"\u00b120 %","Inductance":"10.58 \u03bcH","Termination":"SMT","Type":"Power","Resistance DC":"0.031 Ohms"}...

{"Terminal Finish":"NOT SPECIFIED","Inductance-Nom (L)":"10.58 uH","Operating Temperature-Max":"85 Cel","Tolerance":"20 %","Status":"ACTIVE","Lead Free":"Yes","Operating Temperature-Min":"-40 Cel","Core Material":"POWDERED IRON","Number of Functions":"2","Inductor Application":"POWER INDUCTOR","Shape/Size Description":"RECTANGULAR PACKAGE","DC Resistance":"0.0310 ohm","EU RoHS Compliant":"Yes","Terminal Placement":"ON CIRCLE","Rated Current-Max":"2.5 A","Terminal Shape":"ONE SURFACE","Manufacturer Series":"...

{"Category":"Inductors, Coils, Chokes","Number of Coils":"2","Catalog Drawings":"Parallel Connection Pin Out Series Connection Pin Out Ratio Transformer Pin Out CTX-[1,2,(1,2)P,(1,2)A] Series Footprint CTX-(2,2P,2A) Series","Operating Temperature":"-40\u00b0C ~ 85\u00b0C","Package / Case":"Nonstandard","Tolerance":"\u00b120%","Inductance - Connected In Parallel":"10.58\u00b5H","DC Resistance (DCR) - Series":"125 mOhm Max","Shielding":"Unshielded","Product Photos":"CTX10-2-R CTX10-2-R","PCN Assembly/Origin":...

{"Failure Rate":"Not Required","Packaging ":"Tape and Reel","Number of Terminals":"4","Military Standard":"Not Required","Technology":"Wirewound","Product Height (mm)":"5.97(mm)","Rad Hardened":"No","Test Frequency":"0.1(MHz)","Operating Temp Range":"-40C to 125C","Product Depth (mm)":"11.43(mm)","Product Diameter (mm)":"Not Required(mm)","Core Material":"Amorphous Metal","Inductance":"10.58/42.3(uH)","Tolerance (+ or -)":"20%","Type":"Power","Product Length (mm)":"11.43(mm)"}...
