Product Datasheet Search Results:
6 Pages, 82 KB, Original- BCW89T/R
- Nxp Semiconductors / Philips Semiconductors
- PNP general purpose transistor - fT min: 100 MHz; hFE max: 260 ; hFE min: 120 ; I<sub>C</sub> max: 100 mA; Polarity: PNP ; Ptot max: 250 mW; VCEO max: 60 V
Product Details Search Results:
Semiconductors.philips.com/BCW89T/R
{"V(CE)sat Max.(V)":"300m","Absolute Max. Power Diss. (W)":"350m","V(BR)CBO (V)":"80","h(FE) Min. Static Current Gain":"120","I(C) Abs.(A) Collector Current":"100m","h(FE) Max. Current gain.":"260","@V(CBO) (V) (Test Condition)":"20","I(CBO) Max. (A)":"100n","Package":"SOT-23","@V(CE) (V) (Test Condition)":"5.0","f(T) Min. (Hz) Transition Freq":"150M","V(BR)CEO (V)":"60","Military":"N","@I(C) (A) (Test Condition)":"2.0m","C(obo) (Max) (F)":"4.5p"}...
999 Bytes - 10:12:51, 05 January 2026
